KEF CODA W

Model: Coda W

Drive units Uni-Q Driver Array:

HF: 25 mm aluminium dome

LF/MF: 130 mm magnesium/aluminium alloy cone

Frequency range (-6dB): 38 Hz – 20 kHz

Depends on EQ settings

Frequency response (±3dB): 41 Hz – 20 kHz

Depends on EQ settings

Amplifier output power (per speaker): LF: 70W HF: 30W

Amplifier class (per speaker): LF: Class D HF: Class D

Max SPL (measured at 1m): 102 dB

Wireless streaming features: Bluetooth 5.4, aptX Adaptive™, aptX Lossless™

Source resolution:

• Optical up to 96kHz/24bit
• USB Type-C up to 192kHz/24bit
• HDMI up to 1.411 Mbps PCM

Depends on source resolution

Interspeaker connection: Wired: all sources resampled to 96kHz/24bit PCM

Dimensions (HWD per speaker): 285 x 168 x 268 mm

Weight (per set): 11.3 kg

Power input: 100 – 240VAC 50/60Hz

Power consumption: 200W (operating power) / <0.5W (standby power)

Primary speaker inputs: HDMI ARC, Optical, USB Type-C, RCA (LINE), RCA (PHONO), USB Type-C (interspeaker)

Secondary speaker inputs: USB Type-C (interspeaker)

Outputs: RCA Subwoofer output, USB Type-C (interspeaker), USB Type-C (5V DC)

Finishes: Vintage Burgundy, Nickel Grey, Moss Green, Midnight Blue, Dark Titanium
